Name: FD63T100 - Siemens 3-Pole Trip Unit for FD Frame, 100 A, 600 V
Brand: Siemens
SKU: FD63T100-New
Price: 582.36 USD
Availability: InStock

Siemens 3-Pole Trip Unit for FD Frame, 100 A, 600 V

Current: 100Poles: 3Voltage: 600VConnection: Bolt-On

Choose your condition

Compare New & Re-Certified

New
Original equipment manufacturer (OEM) products that have never been energized. New items may come in their original factory packaging or may be unused components removed from new panels. Packaging and cosmetic appearance can vary; contact our team for details or photos of the available unit.

Re-Certified
Original equipment manufacturer (OEM) products that have previously been energized and have been inspected, tested, and recertified for return to service. These items may show signs of prior use. Contact our team for details about the unit’s condition, testing documentation, and applicable warranty.

Ask about this part →

Variant

$582.36 $4,392.00

Save $3,809.64

25 In stock, ready to be shipped

View warranty coverage Return eligibility

Need it urgently? Call to confirm shipping options

Buying for a project? Request a quote

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

Product Description & Specifications

Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.

Manufacturer: Siemens
Sub-Category: Trip Units & Programmers
Series: Sentron Series
Frame: FD
Rated current: 100
Max current rating: 100
Voltage: 600V
Poles: 3
Phases: 3
Interrupting rating: 35kA@480V
Trip functions: LI - Long Time and Instantaneous Trip
Protection: Thermal Magnetic
Connection: Bolt-On
Frequency: 50/60 Hz
Country of origin: Mexico

Show all specifications (8 more)

Frame Size: 100
Temp Rating: -13°F to 158°F (-25°C to 70°C)
Amperage Maximum: 100
Compatible Frames: FD,HFD,HHFD
UPC: 783643211926
GTIN: 00783643211926
Weight: 1.208
Certification: UL, CSA, IEC

Product description & additional details

FD63T100

FD63T100 is a Siemens Sentron FD-frame molded case circuit breaker trip unit designed for thermal magnetic overcurrent protection in industrial and commercial applications. This interchangeable trip unit is engineered for bolt-on installation and provides reliable protection with a 22 kA interrupt rating at 600 VAC. The unit features a compact design that integrates seamlessly into FD-frame breaker assemblies, offering consistent performance across 50/60 Hz systems. Key Specifications

Manufacturer: Siemens
Part Number: FD63T100
Amperage Rating: 100 Amps
Poles: 3-Pole
Voltage Rating: 600 VAC
Interrupt Rating: 22 kAIC
Frame: FD
Trip Type: Thermal Magnetic
Frequency: 50/60 Hz
Product Type: Interchangeable Trip Unit Only
Operating Temperature: 40 degrees C
Weight: 1.208 lb
