PLA34120U33A - Square D PowerPact P 1200A 3-Pole 480VAC Molded Case Circuit Breaker

PLA34120U33A

PLA34120U33A is a Square D PowerPact P molded case circuit breaker designed for reliable power distribution protection.This circuit breaker features a 1200 ampere rating with 3 poles and is rated for 480 volts AC operation. It offers a high interrupting rating of 100 kA at 480VAC, ensuring robust fault current interruption capabilities. The breaker is part of the PowerPact P series and supports continuous current operation at 80% rating.

Key Specifications
• Manufacturer: Square D
• Series/Frame: PowerPact P
• Amperage: 1200A
• Voltage Rating: 480VAC
• Number of Poles: 3
• Interrupting Rating: 100 kA at 480VAC
• Continuous Current Rating: 80%
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: PLA34120U33A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PLA
• Voltage : 480
• Amperage : 1200
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Frame Size : P Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Solid State



Product Data

• UPC : 762179036777
• Country of Origin : United States
• Dimensions : 16.16 in (410.46 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 4 x AWG 3/0...500 kcmil aluminium/copper
