NS100L - Schneider Electric Compact NS100L Circuit Breaker 100A 3 Pole Thermal Magnetic Trip 150kA 415VAC 50/60Hz

NS100L

NS100L is a Compact NS100L series circuit breaker from Schneider Electric, designed for reliable protection in industrial and commercial power distribution systems. This 3-pole device features a thermal magnetic trip unit and is rated for 100A continuous current at 40°C and 65°C ambient temperatures. The breaker is compatible with fixed mounting applications and provides robust protection for circuits up to 415VAC at 50/60Hz. The Compact NS100L series is engineered for high performance and safety, with a short-circuit interrupting rating of 150kA at 415VAC. It is suitable for use in a wide range of electrical installations requiring dependable circuit protection and easy integration.

• Manufacturer: Schneider Electric
• Series/Frame: Compact NS100L
• Rated Current: 100A at 40°C and 65°C
• Number of Poles: 3
• Mounting Type: Fixed
• Interrupt Rating: 150kA at 415VAC 50/60Hz
• Rated Insulation Voltage: 750VAC 50/60Hz
• Rated Impulse Withstand Voltage: 8kV
• Network Frequency: 50/60Hz
• Maximum AC Voltage: 690VAC
• Trip Unit Type: Thermal Magnetic
• Compliance: IEC 60947-2

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NS100L
• Manufacturer : Schneider Electric
• Brand : Merlin Gerin
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Compact
• Type : NS
• Voltage : 690
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 150kA@415V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Weight : 5
