HLL36125LV - Square D 125A 600V 3 Pole PowerPact HLL Molded Case Circuit Breaker

HLL36125LV

HLL36125LV is a Square D PowerPact HLL series molded case circuit breaker designed for 3 pole, 125 ampere, 600 volt applications.This circuit breaker features a thermal-magnetic trip unit with long-time and instantaneous (LI) trip functions, a 100kA interrupting rating at 480V, and feed-thru design suitable for reverse fed applications. It is UL listed and includes line and load side lug terminals for easy installation.

• Manufacturer: Square D
• Series/Frame: PowerPact HLL
• Amperage: 125A
• Voltage Rating: 600V
• Poles: 3
• Interrupting Rating: 100kA at 480V
• Trip Unit: Thermal Magnetic with LI (Long-Time and Instantaneous)
• Mounting Type: Feed-Thru
• Certifications: UL Listed
• Application: Suitable for reverse fed installations
• Terminal Type: Line and load side lug terminals

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLL36125LV
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
