NC0240 - Schneider Electric 40A 120/240V 2 Pole Stab-Lok Circuit Breaker Plug-In

NC0240

NC0240 is a Schneider Electric Stab-Lok miniature circuit breaker rated for 40 amps and 120/240 volts with 2 poles and plug-in mounting.This circuit breaker features a thermal magnetic trip unit, a 10 kA interrupt rating, and screw terminal connections compatible with AWG 14 to AWG 6 copper wire. It is designed for residential and light commercial applications requiring reliable overcurrent protection. The breaker is CSA certified, RoHS compliant, mercury free, and suitable for use in Stab-Lok panelboards.

• Amperage: 40 A
• Voltage Rating: 120/240 V AC
• Poles: 2P
• Interrupt Rating: 10 kA
• Mounting Type: Plug-in
• Trip Unit: Thermal Magnetic
• Wire Size: AWG 14 to AWG 6 copper
• Terminal Type: Screw connector
• Series/Frame: Stab-Lok
• Certifications: CSA
• RoHS Compliant and Mercury Free

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NC0240
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Stab-Lok
• Type : NC
• Voltage : 240
• Amperage : 40
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 047569176890
• Dimensions : Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
• Weight : 0.39
• Certification : CSA
• Wire Size : AWG 14...AWG 6 copper
