BDA34060Y - Schneider Electric PowerPact B Circuit Breaker 60A 3 Pole 480Y/277V AC I-Line 18kA

BDA34060Y

BDA34060Y is a Schneider Electric PowerPact B circuit breaker designed for reliable power distribution protection.This 3-pole circuit breaker features a 60 ampere rating and operates at 480Y/277 volts AC with an interrupt rating of 18kA at 480/277V. It uses an I-Line mounting system and includes a thermal magnetic trip unit. The breaker supports AWG 14 to 2/0 aluminum/copper lugs and complies with UL, CSA, NOM, IEC, CCC certifications, and is CE marked. It is RoHS and REACh compliant, with a durable design rated for 10,000 electrical cycles.

Key Specifications
• Amperage: 60A
• Voltage: 480Y/277V AC
• Poles: 3
• Mounting Type: I-Line
• Interrupt Rating: 18kA at 480/277V
• Series/Frame: PowerPact B
• Trip Unit: Thermal Magnetic
• Connection: I-Line lug connection
• Certifications: UL, CSA, NOM, IEC, CCC, CE
• Environmental Compliance: RoHS, REACh
• Electrical Durability: 10,000 cycles

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BDA34060Y
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : BDA
• Voltage : 480
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Al Mechanical Lug OFF End, I-Line ON End
• Frame Size : 125A/BD
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 2 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901046356
• GTIN : 03606481152435
• Country of Origin : Mexico
• Dimensions : 5.4 in (137 mm) x 3.2 in (81 mm) x 3.5 in (89 mm) (Height x Width x Depth)
• Weight : 3.79
• Panel Type : Electrical Distribution Equipment, Industrial Control Panels
• Standards : EN/IEC 60947-2, NEMA AB1, UL 489, EN/IEC 60947-5-1, NMX J-266, GB 14048.2, CSA C22.2 No 5
• Certification : UL, IEC, CCC, EAC, CSA, NOM
• Wire Size : AWG 14...AWG 2/0 aluminium/copper
