HJA260305 - Square D 30A 600V 2-Pole PowerPact H-Frame Molded Case Circuit Breaker I-Line

HJA260305

HJA260305 is a Square D PowerPact H-Frame molded case circuit breaker with a 30 amp rating and 2 poles designed for I-Line mounting.This circuit breaker features a 600 Vac/250 Vdc operational voltage rating, 150 amp frame, and a 25kA interrupt rating at 600 Vac. It uses a fixed thermal-magnetic trip unit for reliable overload and short-circuit protection. The breaker mounts on I-Line with isolated plug-on jaws and a mechanical bracket for secure installation. It complies with UL489 standards and has an IP40 protection rating.

• Amperage: 30A trip, 150A frame
• Voltage: 600 Vac / 250 Vdc operational
• Poles: 2
• Mounting Type: I-Line plug-on
• Interrupt Rating: 25kA at 600 Vac
• Series/Frame: PowerPact H-Frame 150 AF
• Trip Unit: Fixed thermal-magnetic
• Protection: Overload and short circuit
• Operating Mode: Manual toggle
• Certifications: UL489
• Degree of Protection: IP40

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260305
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 785901601289
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
