FAP36100 - Square D 100 Amp 600V 3-Pole Molded Case Circuit Breaker, FAP Series, Bolt-On Mount, 18kA @ 480V Interrupt Rating, Thermal Magnetic Trip

FAP36100

FAP36100 is a Square D molded case circuit breaker designed for reliable circuit protection in commercial and industrial applications.

This 3-pole, 100 amp breaker is rated for 600V AC and features a bolt-on mounting style for secure installation. It is part of the FAP series and utilizes a thermal magnetic trip unit for responsive overcurrent protection. The breaker offers an interrupting capacity of 18kA at 480V, 25kA at 240V, and 14kA at 600V, ensuring robust performance across a range of electrical systems. Certified for re-installation and tested to industry standards, the FAP36100 is a trusted choice for power distribution equipment.

Key Specifications
• Part Number: FAP36100
• Manufacturer: Square D
• Amperage: 100A
• Voltage: 600V AC (250V DC)
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 18kA @ 480V, 25kA @ 240V, 14kA @ 600V
• Series/Frame: FAP
• Trip Unit: Thermal Magnetic
• Certifications: Tested to NETA specifications, certified for re-installation
• Weight: Approximately 5 lbs
• Application: Commercial/Industrial power distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAP36100
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAP Series
• Type : FAP
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901022176
• GTIN : 00785901966135
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 4.709
