Description
EHD3090Y
EHD3090Y is an Eaton Series C F-frame molded case circuit breaker with a 3-pole configuration and 90 ampere rating.
This complete breaker features fixed thermal and magnetic trip units designed for reliable protection in industrial and commercial electrical systems. It supports a voltage rating of up to 480VAC and 250VDC with a standard interrupting capacity of 14 kA at 480VAC. The breaker operates at 50/60 Hz frequency and is part of Eaton's durable and widely used Series C line, suitable for fixed mounting applications.
- Key Specifications
- Manufacturer: Eaton
- Series: Series C
- Frame Size: F-frame
- Poles: 3
- Amperage: 90A
- Voltage Rating: 480VAC, 250VDC
- Interrupt Rating: 14 kA at 480VAC
- Trip Unit: Fixed thermal and magnetic
- Frequency: 50/60 Hz
- Mounting Type: Fixed
- Part Number: EHD3090Y
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
- Weight : 4
