EHD3010L - Eaton 10A 480V 3-Pole Series C F-Frame Molded Case Circuit Breaker

EHD3010L

EHD3010L is a 10 amp, 480 volt, 3-pole molded case circuit breaker from Eaton's Series C F-frame lineup.This Eaton EHD3010L breaker features a fixed thermal and fixed magnetic trip unit with long-time and instantaneous trip functions. It is designed for panel mounting with feed-thru connection and provides a 14kA interrupting rating at 480V. The breaker includes line and load side lug terminals and complies with standard certifications for industrial circuit protection.

• Manufacturer: Eaton
• Series: Series C
• Frame Type: F-Frame
• Amperage: 10A
• Voltage: 480V AC
• Poles: 3
• Trip Unit: Fixed Thermal / Fixed Magnetic (LI - Long-Time and Instantaneous)
• Interrupt Rating: 14kA at 480V
• Mounting Type: Panel Mount
• Connection: Feed-Thru
• Phase: 3
• Dimensions: 6" x 4.13" x 3.38"
• Weight: 4.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD3010L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 10
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Line and load
• Frame Size : F
• Breaker Type : EHD
• Protection : Thermal Magnetic

Product Data

• UPC : 786679317020
• GTIN : 00786679317020
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.15
• Standards : UL Listed
• Certification : UL Listed
