EHD3015 - Eaton 15 Amp 3 Pole 480V F-Frame Molded Case Circuit Breaker Series C

EHD3015

EHD3015 is a 15 Amp, 3 Pole molded case circuit breaker from Eaton's Series C, designed for industrial panel mounting applications.This Eaton EHD3015 breaker features a fixed thermal and magnetic trip unit, F-frame size, and is rated for 480 Volt AC and 250 Volt DC operation. It has an interrupt rating of 18 kA at 240 VAC and 14 kA at 480 VAC, suitable for heavy-duty industrial use. The breaker is UL, CSA, and CE approved and supports load side mounting with standard pressure terminals.

Key Specifications
• Amperage: 15 A
• Poles: 3
• Voltage Rating: 480 VAC / 250 VDC
• Interrupt Rating: 18 kA at 240 VAC, 14 kA at 480 VAC
• Frame/Series: Series C, F-Frame
• Trip Type: Fixed thermal and magnetic
• Mounting Type: Panel mount
• Certifications: UL, CSA, CE
• Frequency: 50/60 Hz
• Dimensions: Approx. 4.13" W x 3.38" D x 6" H
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: EHD3015
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC



Product Data

• UPC : 786679317044
• GTIN : 00786679317044
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.15
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
