Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
JJL36225YLRP
JJL36225YLRP is a Schneider Electric PowerPact J series circuit breaker rated for 225 amps, 3 poles, and 600 volts AC with a 25kA interrupt rating and thermal magnetic trip unit.This circuit breaker provides reliable overcurrent protection and switching for AC systems. It features a 3-pole design with lug connections and an 80% rated thermal magnetic trip unit. The breaker is UL 489, CSA, NOM, IEC CCC, UKCA, and CE certified, ensuring compliance with multiple safety standards. It supports field-installable accessories to enhance flexibility and reduce inventory needs.
- Amperage: 225 A
- Voltage: 600 VAC
- Poles: 3
- Interrupt Rating: 25 kA at 600 VAC
- Trip Unit: Thermal Magnetic, 80% rated
- Mounting Type: Lug connection
- Series/Frame: PowerPact J
- Certifications: UL 489, CSA, NOM, IEC CCC, UKCA, CE
- Field installable accessories available
- Recyclability potential: 51%
Specifications
- Part Number: JJL36225YLRP
- Manufacturer : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : JJL
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : J Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
