JJL36225T - Square D Powerpact J Frame 225 Amp 3 Pole 600V Thermal Magnetic Circuit Breaker

JJL36225T

JJL36225T is a Square D Powerpact J Frame molded case circuit breaker rated for 225 Amps and 600 Volts with 3 poles and thermal magnetic trip technology.JJL36225T provides reliable overcurrent protection with a breaking capacity of 25 kA at 600 VAC and is UL 489 listed with multiple international certifications including CSA, IEC, CCC, NOM, UKCA, and CE. It features unit mount lug connections and is designed for use in AC systems with continuous current rating at 80%.

• Manufacturer: Square D
• Series/Frame: Powerpact J Frame
• Amperage: 225 Amp
• Voltage Rating: 600 VAC / 250 VDC
• Number of Poles: 3
• Trip Unit Technology: Thermal Magnetic
• Interrupt Rating: 25 kA at 600 VAC (J Frame)
• Mounting Type: Unit Mount Lug
• Certifications: UL 489, CSA, IEC, CCC, NOM, UKCA, CE
• Continuous Current Rating: 80%
• Electrical Connection: Lug line and load

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JJL36225T
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JJL
• Voltage : 600
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901804932
• GTIN : 00785901804932
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.3
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
