Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
JJL36225YL
JJL36225YL is a Schneider Electric PowerPact J-Frame molded case circuit breaker designed for reliable overload and short-circuit protection.JJL36225YL features a 225 Ampere rating, 3 poles, and is rated for use up to 600 VAC or 250 VDC. It includes a thermal magnetic trip unit with long-time and instantaneous trip functions, mounted with unit mount lugs for easy installation. This breaker is UL 489 listed and meets multiple certifications including CSA, NOM, IEC CCC, UKCA, and CE marks.
- Key Specifications
- Amperage: 225 Amp
- Voltage Rating: 600 VAC / 250 VDC
- Number of Poles: 3
- Frame Type: J-Frame
- Interrupt Rating: 65 kA at 480 V, 25 kA at 600 V, 100 kA at 240 V
- Trip Unit: Thermal Magnetic
- Mounting Type: Unit Mount Lugs
- UL Listing: UL 489
- Standards: CSA, NOM, IEC CCC, UKCA, CE
Specifications
- Part Number: JJL36225YL
- Manufacturer : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : JJL
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : J Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
