JDF36250 - Square D 250 Amp 600 Volt 3 Pole PowerPact J Frame Circuit Breaker

JDF36250

JDF36250 is a Square D PowerPact J Frame molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.

This 3 pole circuit breaker is rated for 250 amps and 600 volts AC, featuring a thermal magnetic trip unit for precise overload and short circuit protection. It offers a D interrupt rating and is unit mountable, making it suitable for a variety of panelboard and switchboard installations. The breaker complies with UL 489 standards ensuring safety and performance.

• Amperage: 250 Amp
• Voltage Rating: 600 Volt AC
• Poles: 3 Pole
• Interrupt Rating: D Interrupt
• Mounting Type: Unit Mount
• Frame/Series: PowerPact J Frame
• Trip Unit: Thermal Magnetic
• Certification: UL 489 Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JDF36250
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JDF
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Busbar Connection
• Frame Size : J
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 3/0 AWG (Cu/Al) Max. Wire Size 350 kcmil (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : AB

Product Data

• UPC : 785901272410
• GTIN : 00785901272410
• Country of Origin : Mexico
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.37
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
