HLP36090 - Square D PowerPact H 90A 3-Pole 600VAC Molded Case Circuit Breaker

HLP36090

HLP36090 is a Square D PowerPact H molded case circuit breaker rated for 90 amps and 600 volts AC with 3 poles.HLP36090 features a thermal-magnetic trip unit providing reliable long-time and instantaneous protection. It is designed for plug-in mounting with I-Line style connection and is suitable for use in 3-phase electrical systems. The breaker has an interrupt rating of 50kA at 600VAC and supports 80% continuous current rating. It is UL listed and built on the H-frame platform for compatibility with PowerPact accessories.

Key Specifications
• Amperage: 90 A
• Voltage Rating: 600 VAC
• Poles: 3
• Frame Type: H-Frame
• Trip Unit: Thermal Magnetic
• Interrupt Rating: 50kA @ 600 VAC
• Mounting Type: I-Line Plug-In
• Continuous Current Rating: 80%
• Connection Type: Lugs
• Standards: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLP36090
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HLP
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 060648705504
• GTIN : 03606487055044
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
