HLA360206 - Square D 20 Amp 600V 3 Pole Molded Case Circuit Breaker Powerpact H Frame

HLA360206

HLA360206 is a Square D Powerpact H frame molded case circuit breaker rated for 20 amps and 600 volts with 3 poles.

This circuit breaker features a 3-pole design with a 20 amp continuous current rating and is suitable for use up to 600 VAC. It has a Powerpact H frame and offers a high interrupt rating of 50 kA at 600 VAC. The breaker is UL 489 listed and designed for unit mount or I-line style plug-in applications, providing reliable overload and short circuit protection in industrial and commercial electrical systems.

• Manufacturer: Square D
• Part Number: HLA360206
• Amperage: 20 Amp
• Voltage Rating: 600 VAC
• Poles: 3 Pole
• Frame Type: Powerpact H
• Interrupt Rating: 50 kA at 600 VAC
• Mounting Type: Unit mount / I-line style plug-in
• Trip Unit: Thermal Magnetic
• Certifications: UL 489 Listed, CSA, NEMA, IEC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLA360206
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HLA
• Voltage : 600
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
