HGF26025 - Square D 25A 600V 2 Pole Bolt-On Circuit Breaker Powerpact H Frame

HGF26025

HGF26025 is a Square D 2 pole, 25 amp, 600 volt bolt-on circuit breaker from the Powerpact H frame series.This molded case circuit breaker features thermal magnetic trip units with long time and instantaneous trip functions. It has a high interrupting capacity rated at 35kA at 480V and is suitable for reverse fed applications. The breaker includes line and load side lug terminals and is designed for reliable protection in industrial and commercial electrical systems.

• Manufacturer: Square D
• Amperage: 25A
• Voltage: 600V AC
• Poles: 2
• Frame Type: Powerpact H (HGF series)
• Mounting Type: Bolt-On
• Interrupt Rating: 35kA at 480V
• Trip Unit: Thermal Magnetic with long time and instantaneous trip
• Suitable for reverse fed applications
• Line and load side lug terminals

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HGF26025
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGF
• Voltage : 600
• Amperage : 25
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
