Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
HDP36090
HDP36090 is a Square D 3 pole, 90 amp, 600 Volt molded case circuit breaker with an 18kA interrupt rating at 480V and bolt-on mounting.This circuit breaker features thermal-magnetic trip technology and is designed for reliable protection in industrial and commercial power distribution applications. It supports a 3-pole configuration with a 600V maximum voltage rating and an interrupting capacity of 18,000 amps at 480 volts. The breaker is bolt-on mounted for secure installation and is part of Square D's HDP series, ensuring compliance with UL 489 and other certifications.
- Key Specifications
- Amperage: 90A
- Voltage Rating: 600V
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 18kA @ 480V
- Series/Frame: HDP
- Trip Unit: Thermal-Magnetic
- Certifications: UL 489 Listed
- Part Number: HDP36090
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : HDP
- Voltage : 600
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : H Frame
- Temp Rating : 28-158 °F (-2-70 °C)
- Protection : Thermal Magnetic
- UPC : 606487054873
- GTIN : 03606490000000
- Dimensions : Height 6.42 in (163 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 5
- Wire Size : AWG 14...AWG 3/0 aluminum/copper terminal
