HDP36030 - Square D 30A 600V 3 Pole Molded Case Circuit Breaker PowerPact H Frame

HDP36030

HDP36030 is a 3 pole, 30 amp, 600 volt molded case circuit breaker from Square D's PowerPact H series designed for reliable circuit protection.This thermal magnetic circuit breaker features a 3 pole configuration with a 14kA interrupt rating at 600VAC and 18kA at 480VAC, suitable for industrial and commercial applications. It includes lug-type mounting and complies with UL 489 certification standards.

• Amperage: 30 Amps
• Voltage: 600 VAC
• Poles: 3
• Interrupt Rating: 14kA at 600V, 18kA at 480V
• Frame/Series: PowerPact H
• Trip Unit: Thermal Magnetic
• Mounting Type: Lug
• Certification: UL 489
• Breaking Capacity: 25kA at 240V AC
• Ambient Operating Temperature: -13°F to +158°F

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDP36030
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDP
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug, Terminal Nut
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 60648740534
• GTIN : 03606487405344
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
