2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FD4060L
FD4060L is a 60 Amp, 600 Volt, 4-pole molded case circuit breaker from Eaton's Series C line designed for reliable circuit protection.This Eaton FD4060L circuit breaker features a thermal-magnetic trip unit with long time and instantaneous trip functions. It is a bolt-on type breaker with line and load side lug terminals, rated for 600 Vac and 250 Vdc operation. The breaker has an interrupt rating of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac, suitable for industrial and commercial applications. It complies with UL and CSA certifications and is part of Eaton's robust Series C frame.
- Key Specifications
- Amperage: 60 Amps
- Voltage Rating: 600 Vac, 250 Vdc
- Number of Poles: 4
- Mounting Type: Bolt-On
- Interrupt Rating: 65 kAIC @ 240 Vac, 35 kAIC @ 480 Vac
- Trip Unit: Thermal-Magnetic (Long Time and Instantaneous)
- Series/Frame: Eaton Series C
- Line and Load Side Lug Terminals
- Certifications: UL and CSA Listed
- Part Number: FD4060L
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 600
- Amperage : 60
- Phase : 3
- Poles : 4
- AIC rating : 25kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip Functions
- Frame Size : F Frame
- Protection : Thermal Magnetic
- UPC : 786679283202
- GTIN : 00786679283202
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
