Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD3090YBP10
EHD3090YBP10 is a 90 Amp, 3 Pole molded case circuit breaker from Eaton's Series C, F Frame, designed for reliable circuit protection in industrial and commercial applications.
This Eaton EHD3090YBP10 breaker features a fixed thermal and fixed magnetic trip unit, suitable for 480 VAC maximum voltage and 250 VDC. It has an interrupt rating of 14 kA at 480 VAC and 18 kA at 240 VAC, ensuring high fault current interruption capability. The breaker is designed for load side mounting and operates at 50/60 Hz frequency. It is UL listed for safety and performance compliance.
- Amperage: 90 Amp
- Poles: 3 Pole
- Maximum Voltage: 480 VAC / 250 VDC
- Frame Type: F Frame
- Series: Eaton Series C
- Interrupt Rating: 14 kA at 480 VAC, 18 kA at 240 VAC
- Trip Type: Fixed Thermal / Fixed Magnetic
- Mounting: Load Side
- Frequency: 50/60 Hz
- UL Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: EHD3090YBP10
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
