Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EDC3225
EDC3225 is a Series C molded case circuit breaker from Eaton, designed for reliable electrical protection in commercial and industrial applications. This F-frame, three-pole breaker features a fixed thermal and fixed magnetic trip unit, rated for 225A at 240VAC and 125VDC, with a 200kA interrupt rating. It is suitable for use in panelboards and switchgear requiring robust overcurrent protection.
- Part Number: EDC3225
- Manufacturer: Eaton
- Series: Series C
- Frame: F Frame
- Amperage: 225A
- Voltage: 240VAC / 125VDC
- Poles: 3
- Interrupt Rating: 200kA @ 240VAC
- Mounting Type: Busbar (No Lugs)
- Series/Frame: Series C, F Frame
- Trip Unit: Fixed Thermal/Fixed Magnetic
- Certifications: UL Listed
Specifications
- Part Number: EDC3225
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDC
- Voltage : 240
- Amperage : 225
- Phase : 3
- Poles : 3
- AIC rating : 200kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679455128
- GTIN : 00786679455128
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
