Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
NGB3K020B
NGB3K020B - Siemens 3-pole G-frame circuit breaker rated at 20A and 600VAC with thermal magnetic trip.NGB3K020B is a UL-listed NGB frame molded case circuit breaker designed for panelboard mounting with DIN rail compatibility and loadside lugs.
- Manufacturer: Siemens
- Part Number: NGB3K020B
- Amperage: 20A
- Voltage: 600VAC
- Poles: 3
- Frame: NGB
- Mounting Type: Panel Mount, DIN Rail
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 25kA @ 480VAC
- Interrupt Rating: 14kA @ 600Y/347VAC
- Certifications: UL 489 Listed
Specifications
- Part Number: NGB3K020B
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : VL Series
- Type : NGB
- Voltage : 600
- Amperage : 20
- Phase : 2
- Poles : 3
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Frame Size : GB2 Frame
- Temp Rating : -13¡F-158¡F
- Protection : Thermal Magnetic
Product Data
- UPC : 804766339431
- GTIN : 00804766339431
- Country of Origin : Mexico
- Dimensions : 6.902 x 4.701 x 4.098 inch
- Weight : 2.601
- Certification : UL, IEC
- Wire Size : 14 to 10 AWS, Cu/Al
