Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
NGB3K015B
NGB3K015B - Siemens NGB series 3-pole molded case circuit breaker rated at 15A and 600VAC with thermal magnetic trip.This Siemens NGB3K015B is a low voltage panelboard mount circuit breaker featuring bolt-on mounting, thermal magnetic trip unit, and interrupting ratings of 25kA at 480V and 14kA at 600Y/347V. It is certified UL489 and mounts directly on panelboards with loadside lugs.
- Amperage: 15A
- Voltage: 600VAC
- Poles: 3
- Mounting Type: Bolt-On
- Series/Frame: NGB
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 25kA at 480V
- Interrupt Rating: 14kA at 600Y/347V
- Certifications: UL489
Specifications
- Part Number: NGB3K015B
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : VL Series
- Type : NGB
- Voltage : 600
- Amperage : 15
- Phase : 2
- Poles : 3
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Frame Size : GB2 Frame
- Temp Rating : -13¡F-158¡F
- Protection : Thermal Magnetic
Product Data
- UPC : 804766339424
- GTIN : 00804766339424
- Country of Origin : Mexico
- Dimensions : 6.902 x 4.799 x 4.098 inch
- Weight : 2.161
- Certification : UL, IEC
- Wire Size : 14 to 10 AWS, Cu/Al
