JLL36250T - Square D PowerPact J 250A 3-Pole 600V Molded Case Circuit Breaker

JLL36250T

JLL36250T is a Square D PowerPact J series molded case circuit breaker rated for 250 amperes at 600 volts AC or 500 volts DC with three-pole configuration and thermal magnetic trip protection. This 80% rated breaker features an L-frame design with surface mounting capability and line/load lug connections suitable for wire sizes from 3/0 AWG to 350 kcmil aluminum or copper. The unit operates at 50/60 Hz frequency and includes toggle actuator control for reliable manual operation in industrial and commercial power distribution applications.

• Amperage Rating: 250 A
• Voltage Rating: 600 VAC / 500 VDC
• Number of Poles: 3
• Frame Size: L
• Trip Type: Thermal Magnetic
• Interrupt Rating: 20/50/100/125 kA
• Mounting Type: Surface
• Connection Type: Line/Load Lug
• Wire Size: 3/0 AWG to 350 kcmil Al/Cu
• Frequency: 50/60 Hz
• Rating: 80% Rated
• Certifications: UL 489, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JLL36250T
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901660828
• GTIN : 00785901660828
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.3
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
