JGL26175 - Square D 175 Amp 600 VAC 2 Pole PowerPact J Molded Case Circuit Breaker

JGL26175

JGL26175 is a Square D PowerPact J Molded Case Circuit Breaker designed for reliable overload and short circuit protection.This circuit breaker features a 175 ampere rating with a 600 VAC voltage rating and 2 poles. It uses a thermal magnetic trip unit with a trip range of 875 to 1750 amps and has an interrupt rating up to 65 kA at 240 VAC. The breaker is unit mounted and supports wire sizes from 4 to 4/0 AWG aluminum or copper. It is built on the J frame series and includes line/load lug connections. The breaker is rated for 50/60 Hz frequency and operates at a temperature rating of 40 degrees Celsius.

• Manufacturer: Square D
• Part Number: JGL26175
• Amperage: 175 A
• Voltage Rating: 600 VAC / 250 VDC
• Number of Poles: 2
• Interrupt Rating: Up to 65 kA at 240 VAC
• Frame/Series: PowerPact J
• Trip Unit: Thermal Magnetic
• Mounting Type: Unit Mount
• Wire Size: 4 to 4/0 AWG Al/Cu
• Frequency: 50/60 Hz
• Operating Temperature: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGL26175
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGL
• Voltage : 600
• Amperage : 175
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/JG
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 3 AWG Max. Wire Size 350 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : Not Applicable

Product Data

• UPC : 785901683162
• GTIN : 00785901683261
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.65
• Panel Type : I Line Panelboards
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 4...AWG 4/0 aluminium/copper terminal
