JGL26225 - Square D PowerPact J Frame 225A 600V 2 Pole Molded Case Circuit Breaker

JGL26225

JGL26225 is a Square D PowerPact J Frame 225A 600V 2 Pole Molded Case Circuit Breaker designed for reliable overload and short circuit protection in commercial and industrial applications. This thermal magnetic, current limiting, adjustable type circuit breaker features a unit mount design, making it easy to install and versatile for a wide range of terminal options. It is UL 489 listed and meets multiple international standards for safety and performance.

• Part Number: JGL26225
• Manufacturer: Square D
• Series/Frame: PowerPact J Frame
• Amperage: 225A
• Voltage: 600V AC, 500V DC
• Poles: 2
• Mounting Type: Unit Mount
• Interrupt Rating: 25kA @ 600V AC
• Trip Unit: Thermal Magnetic, Adjustable
• Certifications: UL 489, CSA, CE, RoHS
• Standards: IEC 60947-2, CSA C22.2 No. 5, NEMA AB1
• Dimensions: 4.09" W x 3.39" D x 7.52" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGL26225
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGL
• Voltage : 600
• Amperage : 225
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/JG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 3 AWG Max. Wire Size 350 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : Not Applicable

Product Data

• UPC : 785901683162
• GTIN : 00785901683162
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.699 lb
• Panel Type : I Line Panelboards
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
