JDL26250
JDL26250 is a Square D PowerPacT J-Frame molded case circuit breaker designed for reliable overcurrent protection in commercial and industrial applications.
This thermal magnetic, current-limiting circuit breaker features a 250A continuous current rating, 600VAC maximum voltage, and 2-pole construction with feed-thru lugs for flexible installation. It offers a 14kA interrupting capacity at 600VAC, dual-break rotating contacts for enhanced short-circuit performance, and an integral push-to-trip button for manual testing. The JDL26250 is unit mount, complies with UL 489, CSA, NOM, IEC, and CE standards, and is suitable for both AC and DC systems.
-
Key Specifications
- Amperage: 250A
- Voltage: 600VAC, 250VDC
- Poles: 2
- Mounting Type: Unit mount, feed-thru lugs
- Interrupt Rating: 14kA @ 600VAC, 18kA @ 480VAC, 25kA @ 240VAC
- Series/Frame: PowerPacT J-Frame
- Trip Unit: Thermal magnetic, adjustable (LOW: 1250A, HIGH: 2500A)
- Certifications: UL 489 Listed, CSA, NOM, IEC, CE, UKCA
- Dimensions: 7.52" H x 4.09" W x 3.39" D
- Weight: 5.29 lbs
- Frequency: 50/60 Hz
- Connection: Line and load side lugs
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: JDL26250
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : JDL
- Voltage : 600
- Amperage : 250
- Phase : 1
- Poles : 2
- AIC rating : 18kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Terminal Connection : Line/Load Lug
- Frame Size : 250A/JD
- Temp Rating : 28-158 °F (-2-70 °C)
- MCM Size : Min. Wire Size 3/0 AWG Max. Wire Size 300 MCM
- Breaker Type : Standard
- Protection : Thermal Magnetic
- Phase Connection : Not Applicable
Product Data
- UPC : 785901839880
- GTIN : 00785901839880
- Country of Origin : Mexico
- Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
- Weight : 4.718
- Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
- Certification : UL, CSA, NOM
- Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
