- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
JDC3200W
JDC3200W is a 200 amp, 600 volt, 3-pole molded case circuit breaker from Eaton's Series C J-frame line designed for reliable circuit protection.This Eaton JDC3200W circuit breaker features a fixed thermal and fixed magnetic trip unit, providing current limiting and ultra-high interrupting capacity. It is rated for 200 amps continuous current and suitable for use up to 600 volts AC. The breaker has a 3-pole configuration and is designed without terminals for flexible mounting options. It belongs to the JDC frame style, known for durability and performance in industrial and commercial applications.
- Key Specifications
- Amperage: 200 A
- Voltage Rating: 600 V AC, 250 V DC
- Poles: 3
- Frame/Series: JDC (J-frame), Series C
- Trip Unit: Fixed thermal, fixed magnetic
- Interrupt Rating: Up to 100kA at 480 V AC
- Mounting Type: Without terminals (W/O terminals)
- Current Limiting: Yes
- Suitable for reverse fed applications
- Part Number: JDC3200W
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : JDC
- Voltage : 600
- Amperage : 200
- Phase : 3
- Poles : 3
- AIC rating : 100kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : J Frame
- Protection : Thermal Magnetic
- GTIN : 00621037092921
- Weight : 15
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
