Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
HMCP150U4CB
HMCP150U4CB is a 3-pole molded case motor circuit protector from Eaton's Series C family, rated for 150 amps at 600 volts with magnetic-only trip protection. This feed-thru mounted breaker provides instantaneous protection for motor starter applications with a magnetic trip range of 750-2500 amps. Key Specifications
- Amperage Rating: 150A
- Voltage: 600VAC, 250VDC
- Poles: 3-Pole
- Series: Series C
- Type: Motor Circuit Protector (MCP)
- Trip Function: Instantaneous (Magnetic Only)
- Magnetic Trip Range: 750-2500A
- Terminal Material: Non-aluminum
- Mounting: Feed-Thru
- Certifications: UL Listed, CSA Certified
- Dimensions: 8 in L x 5 in H x 5 in W
- Weight: 4.5 lb
Specifications
- Part Number: HMCP150U4CB
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : HMCP
- Voltage : 600
- Amperage : 150
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : I - Instantaneous
- Frame Size : F Frame
- Protection : Magnetic Only
Product Data
- Weight : 5
