HLP36045 - Square D PowerPact H 45A 3P 600V Molded Case Circuit Breaker

HLP36045

HLP36045 is a Square D PowerPact H series molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This three-pole breaker provides 45 amp current rating and is rated for 600 volts, making it suitable for a wide range of applications requiring robust overcurrent protection. The HLP36045 features a bolt-on mounting style and a thermal magnetic trip unit with long-time and instantaneous protection. It is compatible with I-Line style plug-in bus systems and offers a high interrupting capacity, ensuring dependable performance under fault conditions.

• Part Number: HLP36045
• Manufacturer: Square D
• Series: PowerPact H
• Amperage: 45A
• Poles: 3
• Voltage: 600V
• Mounting Type: Bolt-On
• Interrupt Rating: 100kA @ 480V
• Interrupt Rating: 125kA @ 240V
• Interrupt Rating: 50kA @ 600V
• Trip Unit: Thermal Magnetic, LI (Long-Time and Instantaneous)
• Connection: I-Line Style Plug-In

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLP36045
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HLP
• Voltage : 600
• Amperage : 45
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 060648705502
• GTIN : 03606487055020
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
