HLA360356 - Square D 35A 600V 3 Pole I-Line Style Plug-In Circuit Breaker

HLA360356

HLA360356 is a Square D 3 pole circuit breaker with a 35 ampere rating and 600 volt AC capacity designed for industrial power distribution applications.

This molded case circuit breaker features an I-Line style plug-in mounting and thermal magnetic trip unit with long-time and instantaneous trip functions. It offers a high interrupt rating of 100kA at 480V, suitable for reliable protection in demanding electrical systems. The breaker is current limiting and designed for reverse fed applications, ensuring versatility and safety in installation. It is UL listed and built on the HLA series frame.

Key Specifications
• Manufacturer: Square D
• Amperage: 35 Amps
• Voltage: 600 VAC
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 100kA at 480V
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous
• Series/Frame: HLA
• Current Limiting: Yes
• Suitable for Reverse Fed Applications: Yes
• UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLA360356
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HLA
• Voltage : 600
• Amperage : 35
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
