HJL26060 - Square D PowerPact H Frame 60 Amp 600VAC 2 Pole Molded Case Circuit Breaker

HJL26060

HJL26060 is a Square D PowerPact H Frame 60 Amp 2 Pole molded case circuit breaker designed for reliable overload and short circuit protection in industrial and commercial applications. This breaker features thermal magnetic trip technology, current limiting design, and is suitable for use in 600VAC systems with line and load side lug terminals. It is UL 489 listed and meets a wide range of industry standards for safety and performance. The HJL26060 is a robust solution for panel mount installations, offering a 65kAIC interrupt rating at 480VAC and 25kAIC at 600VAC. Its non-interchangeable trip unit and feed-thru design make it ideal for reverse fed applications. The breaker is rated for both 80% and 100% continuous load and is suitable for a variety of mounting configurations including unit mount and I-line.

• Part Number: HJL26060
• Manufacturer: Square D
• Series/Frame: PowerPact H Frame
• Amperage: 60 Amp
• Voltage: 600 VAC, 250 VDC
• Poles: 2 Pole
• Interrupt Rating: 65kAIC @ 480VAC, 25kAIC @ 600VAC
• Mounting Type: Unit Mount, I-line, Drawout
• Terminal Type: Lug
• Trip Unit: Thermal Magnetic, Non-Interchangeable
• Standards: UL 489, CSA, CE, RoHS, NEMA AB1
• Application: Industrial, Commercial, OEM

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJL26060
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJL
• Voltage : 600
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901706625
• GTIN : 00785901706625
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.957
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
