HJL26020 - Square D 20 Amp 2 Pole 600V Thermal Magnetic Circuit Breaker PowerPact H Frame

HJL26020

HJL26020 is a Square D 20 Amp 2 Pole thermal magnetic molded case circuit breaker designed for reliable power distribution protection.This PowerPact H frame breaker supports up to 600V AC and 250V DC with a 25kA interrupt rating at 600VAC. It features a unit mount design with thermal magnetic trip unit rated at 80%, UL 489 listed, and certified by CSA, CE, and other international standards. Dimensions are approximately 6.4 in height, 4.09 in width, and 3.4 in depth.

Key Specifications
• Amperage: 20 Amp
• Voltage Rating: 600V AC, 250V DC
• Poles: 2
• Interrupt Rating: 25kA @ 600VAC
• Mounting Type: Unit Mount
• Trip Unit: Thermal Magnetic, 80% Rated
• Series/Frame: PowerPact H Frame
• Certifications: UL 489, CSA, CE, NEMA, IEC
• Dimensions: 6.4 in H x 4.09 in W x 3.4 in D
• Current Limiting Type

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJL26020
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJL
• Voltage : 600
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901955825
• GTIN : 00785901955825
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
