HGL36045 - Square D 45 Amp 600 VAC 3 Pole PowerPact H Molded Case Circuit Breaker

HGL36045

HGL36045 is a Square D PowerPact H molded case circuit breaker designed for reliable overload and short circuit protection.This 3 pole breaker features a 45 amp continuous current rating with a maximum voltage of 600 VAC and a G interrupt rating. It is unit mount type and UL 489 listed, suitable for industrial and commercial electrical distribution applications. The thermal magnetic trip unit provides standard 80% or 100% rating options.

• Amperage: 45 Amp
• Voltage Rating: 600 VAC / 500 VDC
• Poles: 3 Pole
• Mounting Type: Unit Mount
• Interrupt Rating: G Interrupt Code (65kA @ 240V, 35kA @ 480V, 18kA @ 600V)
• Frame/Series: PowerPact H Frame
• Trip Unit: Thermal Magnetic
• Certifications: UL 489 Listed, CSA, IEC 60947-2, RoHS Compliant
• Dimensions: Approx. 4.36" L x 4.12" W x 6.4" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGL36045
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGL
• Voltage : 600
• Amperage : 45
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 150A/HG
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 3 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901683117
• GTIN : 00785901683117
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.145
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
