HGA36060U44X - Schneider Electric PowerPact H-Frame 60A 3 Pole 600V I-Line Circuit Breaker Micrologic 6.2A 18kA

HGA36060U44X

HGA36060U44X is a molded case circuit breaker from the Schneider Electric PowerPact H-Frame series, designed for reliable protection in industrial and commercial power distribution systems. This breaker features a 60A current rating, 3-pole configuration, and is rated for 600V AC operation with an interrupt rating of 18kA at 600V AC. It is built for I-Line mounting and includes the Micrologic 6.2A trip unit for advanced protection and monitoring capabilities. The HGA36060U44X is engineered for high performance and safety, supporting ABC phase connections and offering a compact design suitable for demanding applications. It is UL 489 listed and complies with CSA, NOM, IEC, and CE standards, ensuring broad compatibility and regulatory acceptance.

• Part Number: HGA36060U44X
• Manufacturer: Schneider Electric
• Series/Frame: PowerPact H-Frame
• Amperage: 60A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: I-Line
• Interrupt Rating: 18kA at 600V AC
• Phase: ABC
• Trip Unit: Micrologic 6.2A
• Certifications: UL 489, CSA, NOM, IEC, CE
• UPC: 785901588535

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGA36060U44X
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGA
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Temp Rating : -13–158 °F (-25–70 °C)

Product Data

• UPC : 785901588535
• GTIN : 00785901588535
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 8.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
