HDM36090 - Square D PowerPact H-Frame 3 Pole 90A 600V Molded Case Circuit Breaker

HDM36090

HDM36090 is a Square D PowerPact H-Frame molded case circuit breaker designed for reliable electrical protection in commercial and industrial applications. This 3-pole, 90A unit operates at up to 600V and features a thermal-magnetic trip unit for overload and short-circuit protection. The breaker is built for unit mount installation and is suitable for a wide range of panel configurations. The HDM36090 is part of the PowerPact H-Frame series, known for durability and ease of installation. It offers a standard interrupt rating of 18kA at 480V and is UL 489 listed for safety and compliance. The breaker is designed for use with copper or aluminum conductors and supports versatile terminal options for flexible wiring.

• Part Number: HDM36090
• Manufacturer: Square D
• Series/Frame: PowerPact H-Frame
• Poles: 3
• Amperage: 90A
• Voltage: 600V
• Mounting Type: Unit Mount
• Interrupt Rating: 18kA @ 480V
• Protection Type: Thermal-Magnetic
• Standards: UL 489 Listed
• Terminal Compatibility: Copper/Aluminum
• Application: Commercial, Industrial

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDM36090
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDM
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
