HDF36070 - Square D H Frame 70 Amp 600 VAC 3 Pole Molded Case Circuit Breaker

HDF36070

HDF36070 is a Square D H Frame molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems.This 70 amp, three pole circuit breaker features a thermal-magnetic trip unit and is rated for up to 600 VAC. It is suitable for panel mount applications and offers a robust interrupt rating for demanding environments.

• Part Number: HDF36070
• Manufacturer: Square D
• Amperage: 70 Amp
• Voltage: 600 VAC
• Poles: 3
• Mounting Type: Panel Mount
• Interrupt Rating: 14 kA at 600 VAC
• Frame: H Frame
• Series: PowerPact
• Tripping Mechanism: Thermal-Magnetic
• UL Listed: UL 489

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: HDF36070
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDF
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 606486282406
• GTIN : 03606486282403
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
