HDA260451 - Square D 45A 600V 2-Pole Molded Case Circuit Breaker PowerPact H Frame

HDA260451

HDA260451 is a Square D 2-pole molded case circuit breaker rated for 45 amps and 600 volts, designed for reliable power distribution protection.This PowerPact H frame breaker features thermal magnetic trip units, an interrupt rating of 14kA at 600VAC, and I-Line style plug-in mounting. It is UL listed, CSA certified, and suitable for industrial and commercial electrical applications requiring robust circuit protection.

• Manufacturer: Square D
• Amperage: 45A
• Voltage: 600VAC
• Poles: 2
• Frame/Series: PowerPact H (HDA)
• Interrupt Rating: 14kA @ 600VAC
• Trip Unit: Thermal Magnetic
• Mounting Type: I-Line Plug-In
• Certifications: UL Listed, CSA Certified, CE Compliant
• Phase: Single
• Breaking Capacity: 18kA @ 480VAC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA260451
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 45
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901632528
• GTIN : 00785901632528
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
