EDH3100 - Cutler Hammer 100 Amp 240V 3 Pole Molded Case Circuit Breaker F-Frame Bolt-On

EDH3100

EDH3100 is a Cutler Hammer molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.This 3 pole, 100 amp circuit breaker features a thermal magnetic trip unit and is rated for 240 VAC and 125 VDC operation. It uses an F-frame design with bolt-on mounting for secure installation. The breaker provides a 10kA interrupt rating at 240 VAC and complies with industry certifications for safety and performance.

• Amperage: 100 Amps
• Voltage: 240 VAC, 125 VDC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 10kA at 240 VAC
• Frame/Series: F-Frame, Series C
• Trip Unit: Thermal Magnetic
• Certifications: Industry standard safety certifications

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH3100
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679455401
• GTIN : 00786679455401
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4
• Certification : UL Listed
