CSR2125N - Cutler Hammer 125 Amp 240 Volt 2-Pole Circuit Breaker CSR Frame

CSR2125N

CSR2125N is a 125 Amp, 240 Volt, 2-Pole circuit breaker from Cutler Hammer designed for residential and light commercial applications.This Cutler Hammer CSR2125N circuit breaker features a CSR frame type with a 25 kA interrupt rating, suitable for 120/240 VAC systems. It includes a bolt-on mounting type and lug load side terminations. The breaker is UL, NEMA, and CSA certified, ensuring compliance with industry safety standards. It offers reliable protection with a long-lasting molded case design.

• Amperage: 125 Amp
• Voltage: 120/240 VAC
• Poles: 2
• Frame Type: CSR
• Interrupt Rating: 25 kAIC
• Mounting Type: Bolt-On
• Trip Unit: Thermal Magnetic (LI Trip)
• Wire Size Range: #2 AWG to 300 kcmil
• Application: Residential and Light Commercial
• Certifications: UL, NEMA, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CSR2125N
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CSR Series
• Type : CSR
• Voltage : 240
• Amperage : 125
• Phase : 1
• Poles : 2
• AIC rating : 25kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 78211401973
• GTIN : 00782114019733
• Country of Origin : United States
• Dimensions : 3.1 in x 3.1 in x 2 in (Length/Depth x Height x Width)
• Weight : 2.5
• Certification : UL 489
• Wire Size : 2 to 300 kcmil
