BES3210 - BRAH Electric 100 Amp 240 Volt 3 Phase 3 Wire Fusible Bus Plug

BES3210

BES3210 is a fusible type bus plug designed for industrial busway systems, providing reliable power distribution with a 100 amp rating.

This bus plug operates at 240 volts and supports 3 phase, 3 wire configurations. It is a UL Listed assembly featuring a UL Recognized internal switch and components. The BES3210 is compatible with OEM Bulldog, ITE, and Siemens BD series busway systems and accepts Class R, H, and K fuse types, making it a direct substitute for ITE OEM BOS14323 and BOS14323R models.

Key Specifications
• Amperage: 100 Amp
• Voltage: 240 Volt
• Phases: 3 Phase
• Wires: 3 Wire
• Type: Fusible Bus Plug
• UL Listed Assembly
• UL Recognized Internal Switch
• Compatible with Bulldog / ITE / Siemens BD Series Busway Systems
• Accepts Class R, H, and K Fuse Types

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BES3210
• Manufacturer : BRAH Electric
• Brand : BRAH Electric
• Category : Bus Plug
• Item Subcategory : Fusible
• Family : BD Series
• Type : BOS/BES
• Voltage : 240
• Amperage : 100
• Phase : 3
• AIC rating : 65kA@240V
• Fuse Class : R, H, K
• Wire : 3

Product Data

• UPC : 699252496381
• Country of Origin : China
• Dimensions : 9 61/100 in x 16 7/10 in
• Weight : 45
• Certification : UL Listed, UL Recognized
