BES3203GN - BRAH Electric 30A 240V 3-Phase 4-Wire Fusible Bus Plug BD Series

BES3203GN

BES3203GN is a 30 amp, 240 volt, 3-phase, 4-wire fusible bus plug from BRAH Electric's BD Series designed for industrial busway systems.This bus plug features a fusible style design compatible with Class R, H, and K fuses and includes weather stripping for drip protection. It is UL Listed and UL Recognized as an assembly, suitable for use with OEM Bulldog, ITE, and Siemens BD Series busway systems. The unit provides a 65kA interrupting rating at 240 VAC and includes a ground wire for safety.

• Amperage: 30 Amps
• Voltage: 240 Volts AC
• Phase/Wire: 3 Phase, 4 Wire with Ground
• Type: Fusible Bus Plug (BES / BOS style)
• Fuse Classes: R, H, K
• Interrupt Rating: 65kA at 240V
• UL Listed Assembly
• Weather Stripping for Drip Protection
• Compatible with Siemens, ITE, Bulldog BD Series Busway
• Series: BD

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BES3203GN
• Manufacturer : BRAH Electric
• Brand : BRAH Electric
• Category : Bus Plug
• Item Subcategory : Fusible
• Family : BD Series
• Type : BOS/BES
• Voltage : 240
• Amperage : 30
• Phase : 3
• AIC rating : 65kA@240V
• Fuse Class : R,H,K
• Wire : 4

Product Data

• UPC : 699252496244
• Country of Origin : China
• Dimensions : 9 61/100 in x 11 19/50 in
• Weight : 35
• Certification : UL Listed, UL Recognized
