XTPAXLSA
XTPAXLSA Eaton XT Line-Side Adapter, B Frame
XTPAXLSA is an Eaton XT B-frame line-side adapter for XTPR manual motor protection in UL 508 Type E or Type F combination starter assemblies.
The exact adapter is rated 690V and 60A, accepts 14 through 6 AWG conductors, and carries EN 60947-4-1 certification with CE marking.
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Common Applications
- Creating a Type E self-protected manual combination starter
- Assembling an XT Type F combination motor controller
- Connecting the line side of a B-frame XTPR device
Key Features
- Frame-specific design: Assigned to B-frame XTPR equipment
- Electrical capacity: Published at 690V and 60A
- Conductor accommodation: Supports 14 through 6 AWG wiring
- Commoning-link construction: Finger and back-of-hand protected arrangement
Specifications
- Frame size: B frame
- Operational voltage: 690V
- Uninterrupted current: 60A
- Conductor range: 14 through 6 AWG
- Product dimensions: 4 x 2.75 x 2.5 in
- Product weight: 0.55 lb
- Certification: EN 60947-4-1
- Compliance: CE marked
Product Identification
- Catalog number: XTPAXLSA
- Manufacturer: Eaton
- Product family: XT IEC motor control
- EAN: 4015082625184
- UPC: 015082625188
FAQ
What is XTPAXLSA?
It is Eaton's B-frame XT line-side adapter for XTPR Type E or Type F combination starter configurations.
What electrical ratings apply?
Eaton publishes 690V operational voltage and 60A uninterrupted current.
Which wire sizes can be used?
The exact sheet specifies conductors from 14 through 6 AWG.
Which frame does the part support?
XTPAXLSA is assigned to B-frame XTPR manual motor protection.
What measurements does Eaton provide?
The product measures 4 x 2.75 x 2.5 in and weighs 0.55 lb.
