Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- Eaton
- Brand
- Cutler Hammer
- Sub-Category
- Overload Relay
- Series
- XT Series
- Frame
- XTOB
- Max current rating
- 24
- Poles
- 3
- Country of origin
- United States
- Relay Style
- Thermal
- Amperage Maximum
- 24
- Amperage Minimum
- 16
- UPC
- 782116978212
- GTIN
- 00782116978212
- Dimensions
- 1.811 in x 3.819 in x 2.835 in (Length/Depth x Height x Width)
Show all specifications (2 more)
- Weight
- 0.3 lb
- Certification
- UL/CUL listed
Product description & additional details
XTOB024CC1DP
XTOB024CC1DP is an adjustable thermal overload relay designed for motor protection with a 16 to 24 ampere range.This Cutler Hammer overload relay features a bimetallic design with Class 10 trip characteristics, suitable for use with C25 series motor starters. It mounts directly to any 3-pole C25D definite purpose contactor frame C and provides reliable motor overload protection with manual or automatic reset options.
- Adjustable current range: 16-24 Amps
- Series/Frame: C25 Series, Frame C
- Trip class: Class 10
- Mounting type: Direct mount to 3-pole C25D contactors
- Thermal overload relay type: Bimetallic
- Reset type: Manual or automatic reset
- Poles: 3
- Manufacturer: Cutler Hammer (Eaton)
Specifications
- Part Number: XTOB024CC1DP
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Overload Relay
- Family : XT Series
- Type : XTOB
- Poles : 3
- Relay Style : Thermal
- Amperage Maximum : 24
- Amperage Minimum : 16
Product Data
- UPC : 782116978212
- GTIN : 00782116978212
- Country of Origin : United States
- Dimensions : 1.811 in x 3.819 in x 2.835 in (Length/Depth x Height x Width)
- Weight : 0.3 lb
- Certification : UL/CUL listed
