Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TED134010WL
TED134010WL is a General Electric 3 Pole thermal magnetic circuit breaker rated for 10 Amps and 480 Volts AC. It features a molded case design with copper/aluminum line and load lugs for reliable electrical distribution protection.TED134010WL provides an 18kA interrupt rating at 480V, making it suitable for industrial, motor control centers, lighting, and power distribution applications. It belongs to the TED series frame with a thermal magnetic trip unit and is CSA and UL 489 certified.
- Amperage: 10 Amps
- Voltage: 480 Volts AC
- Poles: 3
- Interrupt Rating: 18kA at 480V
- Frame Type: TED
- Trip Unit: Thermal Magnetic
- Mounting: Molded Case with line/load lugs
- Certifications: CSA Certified, UL 489 Listed
- Application: Industrial, Motor Control, Lighting, Power Distribution
Specifications
- Part Number: TED134010WL
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : E150 Line
- Type : TED
- Voltage : 480
- Amperage : 10
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164069433
- GTIN : 00783164069433
- Weight : 3
- Certification : UL
