Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
MJF36600SA
MJF36600SA is a Schneider Electric PowerPacT M series molded case circuit breaker rated for 600 amperes at 600 volts AC with electronic trip unit and unit mount configuration. This three-pole breaker delivers a 25 kA interrupting rating at 600 VAC and 65 kA at 480 VAC, providing reliable overcurrent protection for industrial and commercial power distribution applications. The standard 80% continuous current rating and common mounting dimensions enable design standardization across PowerPacT M and P-frame breaker ranges.
- Amperage: 600 Amp
- Voltage: 600 VAC
- Poles: 3 Pole
- Frame Type: M Frame
- Mounting: Unit Mount
- Interrupt Rating: 25 kA at 600 VAC, 65 kA at 480 VAC
- Trip Unit: Electronic
- Continuous Rating: 80%
- Certifications: UL 489, CSA, NMX, IEC 60947-2
- Series: PowerPacT
Specifications
- Part Number: MJF36600SA
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : MJF
- Voltage : 600
- Amperage : 600
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : M Frame
- Protection : Solid State
Product Data
- Country of Origin : United States
- Weight : 29
