LT3500TV - Cutler Hammer 500A 600VAC 3-Pole Thermal Magnetic Trip Unit Frame J-K Series C

LT3500TV

LT3500TV is a Cutler Hammer molded case circuit breaker trip unit designed for reliable thermal magnetic protection in high-demand applications.This trip unit features a 500 ampere rating, three-pole configuration, and is non-interchangeable thermal magnetic type. It fits LT circuit breakers with Frame J-K and belongs to Series C. The unit is UL Listed and calibrated for 50°C operation.

Key Specifications
• Amperage Rating: 500 A
• Voltage Rating: 600 VAC
• Number of Poles: 3
• Trip Type: Non-interchangeable Thermal Magnetic
• Frame Size: J-K
• Series: C
• Calibration: 50°C
• Certifications: UL Listed
• Circuit Breaker Type: LT

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LT3500TV
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Series C
• Voltage : 600
• Poles : 3
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic
• Compatible Frames : LD,HLD,LDC

Product Data

• UPC : 78667955602
• GTIN : 00786679556023
• Dimensions : 8.7 in x 5.5 in x 5.3 in (Length/Depth x Height x Width)
• Weight : 3.3
