Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- Schneider Electric
- Sub-Category
- Contactor
- Series
- TeSys D
- Frame
- LC1D
- Rated current
- 18
- Voltage
- 600V
- Poles
- 3
- Phases
- 3
- Coil voltage
- 48 V
- Auxiliary contacts
- 3 NO
- Country of origin
- France
- Temp Rating
- -13°F to 158°F (-25°C to 70°C)
- Horse Power
- 1 hp at 115 V AC 50/60 Hz for 1 phase motors-3 hp at 230/240 V AC 50/60 Hz for 1 phase motors-5 hp at 200/208 V AC 50/60 Hz for 3 phases motors-5 hp at 230/240 V AC 50/60 Hz for 3 phases motors-10 hp at 460/480 V AC 50/60 Hz for 3 phases motors-15 hp at 575/600 V AC 50/60 Hz for 3 phases motors
- Coil Voltage Maximum
- 48
Show all specifications (8 more)
- Full Load Amps
- Full Load Amps-Inductive 18A Full Load Amps-Resistive 32A
- Coil Voltage Minimum
- 48
- Frequency
- 50/60 Hz
- UPC
- 785901475118
- GTIN
- 03389110291872
- Dimensions
- 1.77 in x 3.03 in
- Weight
- 0.791
- Certification
- BV, CCC, CSA, CSA C22.2 No 14, DNV, EN 60947-4-1, EN 60947-5-1, GL, GOST, IEC 60947-4-1, IEC 60947-5-1, LROS, RINA, UL 508, UL Listed
Product description & additional details
LC1D18LE7
LC1D18LE7 is a Schneider Electric 3-pole motor contactor with an 18 amp AC-3 rating and a 208V AC coil designed for motor control applications.
This IEC TeSys D contactor features 3 normally open (NO) main contacts and includes 1 normally open and 1 normally closed auxiliary contact. It supports motor loads up to 10 HP at 460V AC and 5 HP at 230V AC, with a mechanical durability of 15 million operating cycles. The contactor mounts easily on a standard 35mm DIN rail and provides screw clamp terminals with IP20 finger-safe protection. It is suitable for use in 3-phase motor control circuits with a rated operational voltage up to 690V AC and a short-circuit current rating (SCCR) of 100kA.
- Rated current: 18 A AC-3, 32 A AC-1
- Coil voltage: 208 V AC 50/60 Hz
- Poles: 3 NO main contacts
- Auxiliary contacts: 1 NO + 1 NC base mounted
- Motor power rating: 10 HP at 460 V AC, 5 HP at 230 V AC
- Mounting type: DIN rail
- Mechanical durability: 15 million cycles
- Rated operational voltage: up to 690 V AC
- Short-circuit current rating (SCCR): 100 kA
At Es(more...)
Additional Information
This TeSys D IEC Contactor includes a 208 VAC coil.
Specifications
- Part Number: LC1D18LE7
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Motor Control
- Item Subcategory : Contactor
- Family : TeSys D
- Type : LC1D
- Voltage : 600
- Amperage : 18
- Phase : 3
- Poles : 3
- Temp Rating : -13°F to 158°F (-25°C to 70°C)
- Horse Power : 1 hp at 115 V AC 50/60 Hz for 1 phase motors-3 hp at 230/240 V AC 50/60 Hz for 1 phase motors-5 hp at 200/208 V AC 50/60 Hz for 3 phases motors-5 hp at 230/240 V AC 50/60 Hz for 3 phases motors-10 hp at 460/480 V AC 50/60 Hz for 3 phases motors-15 hp at 575/600 V AC 50/60 Hz for 3 phases motors
- Aux Contacts : 3 NO
- Coil Voltage Maximum : 48
- Full Load Amps : Full Load Amps-Inductive 18A Full Load Amps-Resistive 32A
- Coil Voltage Minimum : 48
- Frequency : 50/60 Hz
Product Data
- UPC : 785901475118
- GTIN : 03389110291872
- Country of Origin : France
- Dimensions : 1.77 in x 3.03 in
- Weight : 0.791
- Temp Rating : -13°F to 158°F (-25°C to 70°C)
- Certification : BV, CCC, CSA, CSA C22.2 No 14, DNV, EN 60947-4-1, EN 60947-5-1, GL, GOST, IEC 60947-4-1, IEC 60947-5-1, LROS, RINA, UL 508, UL Listed
